Jetson AGX Orin SOM 32GB

    Edge Computers · HyperEdge Series

    Jetson AGX Orin SOM 32GB

    NVIDIA Jetson AGX Orin series modules deliver upto 200 TOPS of AI performance with power configurable between 15W and 60W. This gives you more than 8X the performance of Jetson AGX Xavier™ in the same compact form-factor for robotics and other autonomous machine use cases.

    ₹2,26,799Excl. GST
    Technical Details

    Specifications

    Technical Specifications

    Product Features

    Technical features and specifications for Jetson AGX Orin SOM 32GB
    FeatureValue
    ProcessorNVIDIA Jetson AGX Orin 32GB
    AI Performance200 TOPS
    GPU1792-core NVIDIA Ampere GPU with 56 Tensor cores
    CPU8-core Arm Cortex-A78AE v8.2 64-bit CPU, 2MB L2 + 4MB L3
    Memory32GB 256-bit LPDDR5, 204.8GB/s
    Storage64GB eMMC 5.1
    Video Encode1x 4K60 (H.265) | 3x 4K30 (H.265) | 6x 1080p60 (H.265) | 12x 1080p30 (H.265)
    Video Decode1x 8K30 (H.265) | 2x 4K60 (H.265) | 4x 4K30 (H.265) | 9x 1080p60 (H.265) | 18x 1080p30 (H.265)
    CSI CameraUp to 6 cameras, 16-channel MIPI CSI-2 D-PHY, upto 40Gbps
    PCIeUp to 2 x8 + 1 x4 + 2 x1, PCIe 4.0 (Root port and endpoint)
    USB3x USB 3.2 (10Gbps), 4x USB 2.0
    Network1x GbE + 1x 10GbE
    Display
    • 1. 1x 8K60, DP 1.4a (+MST)
    • 2. eDP 1.4
    • 3. HDMI 2.1
    Other I/O4x UART, 3x SPI, 4x I2S, 8x I2C, 2x CAN, PWM, DMIC, DSPK, GPIO
    Power consumption15W–40W

    Overview

    Jetson AGX Orin 32GB SOM price in India: Rs 2,26,799 excl GST. 200 TOPS embedded AI module for robotics and vision. Buy online at Core Bolt India today.
