ZED 2i

    Vision Systems & Cameras · ZED Cameras

    ZED 2i

    AI-Powered Stereo Vision for Robotics and Spatial Analytics. Industrial-grade depth camera with neural sensing and modular design for any environment. The plug-and-play USB 3 connectivity makes it compatible with embedded and desktop PC solutions.

    Specifications

    Technical Specifications

    Product Features

    Technical features and specifications for ZED 2i
    FeatureValue
    Dimensions175 mm × 30 mm × 33 mm
    Baseline120 mm
    Weight262 g
    Operating Temperature-10°C to +50°C
    Lens CoverGorilla Glass
    Depth TechnologyNeural Stereo Depth Sensing
    Video Output
    • 1. 2K @ 15 fps (2208 × 1242)
    • 2. 1080p @ 30 fps (1920 × 1080) /720p @ 60 fps (1280 × 720)
    • 3. WVGA @ 100 fps (672 × 376)
    Video RecordingH.264, H.265, or Lossless Encoding (Host-Based)
    Video StreamingIP Streaming via ZED SDK
    Depth ResolutionNative Video Resolution (Ultra Mode)
    Depth Range0.3 m to 20 m
    Ideal Range0.3 m to 12 m
    Depth Frame RateUp to 100 Hz
    Motion SensorsAccelerometer, Gyroscope, Magnetometer, Barometer
    Sensor Data Rate800 Hz
    Pose Update RateUp to 200 Hz
    InterfaceUSB 3.0 Type-C
    Field of View (Wide Lens)110° × 70° × 120°
    Field of View (Narrow Lens)90° × 60° × 100°
    IP RatingIP66
