ZED X GS

    Vision Systems & Cameras · ZED Cameras

    ZED X GS

    The ZED X stereo camera features a global shutter that captures sharp imagery without motion artifacts, even in dynamic environments. Powered by the ZED SDK, it delivers advanced collision avoidance, real-time 3D perception, accurate localization, and semantic scene understanding, making it ideal for demanding automation tasks.

    Specifications

    Technical Specifications

    Product Features

    Technical features and specifications for ZED X GS
    FeatureValue
    Dimensions163.4 mm × 31.8 mm × 36.7 mm
    Baseline120 mm
    Weight239 g
    Operating Temperature-20°C to +60°C
    Depth TechnologyNeural Stereo Depth Sensing
    Video Output
    • 1. 1200p @ 60/30/15 fps (2 × 1920 × 1200 Side-by-Side)
    • 2. 1080p @ 60/30/15 fps (2 × 1920 × 1080 Side-by-Side)
    • 3. 600p @ 120/60/30/15 fps (2 × 960 × 600 Side-by-Side)
    Video RecordingH.264, H.265, or Lossless Encoding (Host-Based)
    Video StreamingIP Streaming via ZED SDK
    Depth Range0.3 m to 20 m (2.2 mm Lens /1.0 m to 35 m (4.6 mm Lens)
    Ideal Range0.3 m to 12 m (2.2 mm Lens /1.0 m to 20 m (4.6 mm Lens)
    Depth Frame RateUp to 100 Hz
    Motion Sensors16-bit Accelerometer (Up to 12g)
    Motion Sensors16-bit Gyroscope (Up to 1000°/s)
    Sensor Data Rate200 Hz
    Pose Update RateUp to 100 Hz
    InterfaceGMSL2 (FAKRA Z Connector)
    Image SensorsDual 2.3 MP Global Shutter Sensors
    Output FormatRAW10
    IP RatingIP67
